Leather Co2 Laser Engraver ,Co2 Laser Cutting Machine With Water Cooling System
(Model: PEDK-6040A)
★Product Introduction
PEDK-6040A small laser engraving machine is an economical and practical small non-metallic laser engraving machine, which adopts imported lenses, high precision linear guide rail and sealed case design. The whole machine is beautiful, practical, powerful and durable. This small laser engraving machine has powerful editing software, strong compatibility, can work off-line, support file formats are: BMP, PLT, AL, DST, DXF and other file formats.
★ Product Features
1. Honeycomb platform, processing area of 600*400 mm, closed processing interval, can be selected according to customer needs automatic lifting platform and rotating fixture.
2. Visual processing: with red light indicating positioning function, quickly determine the machining position, with professional cutting and engraving software, path automatic optimization, intelligent motion control.
3. The cutting effect is very stable: small non-metallic laser engraving machine using imported lenses, small energy loss, high reflectivity, not easy to damage, durable,
4. Smooth cutting curve: small non-metallic laser engraving machine equipped with advanced speed change system, can automatically adjust the cutting speed, to ensure that the inflection point transition natural when cutting, cutting effect is perfect.
5. The laser engraving machine powerful software, support graphics typesetting, large compatibility.
★ Application
1. Applicable materials: organic glass, acrylic, PVC, leather, textile, cloth, rubber, plastic, wood, paper, stone and other non-metallic materials,etc.
2. Applicable industry: It has been widely used in the fields of organic glass products, acrylic handicrafts, lens panels, wood products carvings, veneer cut flowers, advertising products, light box signs, crystal words, display stands, packing boxes, models, toys, furniture and other industries.
★ Technical Date
| Laser Type: | Hermetic and Detached CO2 Laser Tube |
| Laser Wavelength: | 10.64um |
| Laser Power: | 40W | 50W | 60W |
| Working Area: | 600*400(mm) |
| Engraving Speed: | 0-300mm/s |
| Cutting Speed: | 0-30 mm/s |
| Cutting Thickness | 0-10mm (Varies to different materials) |
| Machine Power: | 300-450W |
| Location Type: | Red Pointer positioning |
| Location Accuracy | ±0.1mm |
| Resolution: | 1000dpi |
| Port: | USB 2.0 |
| Working Table: | Honeycomb table |
| Up-down height: | 0-300mm |
| Mini Text Height: | English Letter: 1mm Chinese:2mm |
| Support Software: | Windseal XP / CorelDraw |
| Working Voltage: | AC220v/50hz, AC110v/50hz |
| Working Environment: | Temperature:0-45℃ Humidity:5%-95% |
| Driver Way: | Digital Subdividing Step Driver |
| Laser Device Cooling Type | Circulating Water Cooling |
| Option Item: | Motorized lifting table, Rotary Fixture |
| Rotary System(Optional) | φ10-150×300mm |
| Machine Dimension: | 1020×700×600mm |
| Machine Weight: | 95 kgs |
★ Samples
★Competitive Advantages
1. 100% custom pass guaranteed.
2. Our products have been exported to Germany, Norway, Poland, Finland, Spain, UK, France, Russia, USA, Brazil, Mexico, Australia, Japan, Korea, Thailand, Indonesia, Uruguay and many other countries.
3. Flexible and Untraceable payment terms.
4. Good after-sale service.
5. We offer high quality products at competitive price in quick delivery.
